Name: JBL Stage A170
Brand: JBL
SKU: STAGE_A170BK
Availability: OutOfStock

JBL Stage A170 Powerful Immersive Sound Floorstanding Loudspeaker, 2.5-Way, Dual 5.25" Polycellulose Woofers, HDI Waveguide, Black (Stage A170)

Product Details

Brand: JBL

Weight: 35.10 lbs

Elevate your audio experience with the JBL Stage A170 a premium floorstanding speaker designed to deliver powerful, immersive sound. Perfect for music lovers and home theater enthusiasts, this sleek and modern speaker combines cutting-edge technology with JBL’s renowned audio quality.

Transform your music and home entertainment experience with the JBL Stage A170 Floorstanding Loudspeaker. Designed and engineered at JBL's renowned acoustic engineering facility in Northridge, California, the A170 combines a sleek, space-conscious tower design with powerful JBL audio performance, making it an attractive choice for both dedicated stereo systems and immersive home theater installations.

Its sophisticated 2.5-way architecture features two 5.25-inch (133 mm) polycellulose low-frequency woofers that produce strong, controlled bass, while a 1-inch (25 mm) aluminum dome tweeter handles detailed high frequencies. JBL's patented High-Definition Imaging (HDI™) waveguide is engineered to provide precise imaging and a broad, well-defined soundstage.

With a frequency response extending from 44 Hz to 40 kHz, 89 dB sensitivity and compatibility with amplifiers rated from 20 to 200 watts, the Stage A170 delivers an excellent combination of clarity, dynamic performance and powerful sound from a relatively narrow floorstanding enclosure.

PRODUCT OVERVIEW

The JBL Stage A170 is the most compact floorstanding speaker in JBL's original Stage Series, combining dual 5.25" woofers, an aluminum dome tweeter, HDI waveguide technology and a rear-ported bass-reflex enclosure in an elegant tower design.

KEY FEATURES

2.5-Way Floorstanding Design
Dual 5.25" / 133 mm Polycellulose Woofers
1" / 25 mm Aluminum Dome Tweeter
JBL High-Definition Imaging (HDI™) Waveguide
Recommended amplifier power: 20–200 W
Frequency response: 44 Hz–40 kHz
Sensitivity: 89 dB @ 1 m, 2.83 V
Nominal impedance: 6 Ohms
Rear-firing tuned bass-reflex port
Slim floorstanding cabinet
Black finish

PRODUCT ADVANTAGES

Powerful sound from a slim tower design
Wide frequency response for music and movies
Dual woofers provide strong low-frequency performance
Aluminum tweeter delivers detailed high frequencies
HDI waveguide improves imaging and sound dispersion
Excellent front-channel option for home theater
Suitable for stereo music systems
Elegant design integrates easily into modern living spaces

TECHNICAL SPECIFICATIONS

Specification	JBL Stage A170
Speaker Type	Floorstanding Loudspeaker
System Design	2.5-Way
Low-Frequency Drivers	2 × 5.25" / 133 mm Polycellulose
High-Frequency Driver	1 × 1" / 25 mm Aluminum Dome
Waveguide	JBL HDI™ Waveguide
Recommended Amplifier Power	20–200 W
Frequency Response	44 Hz–40 kHz
Sensitivity	89 dB @ 1 m, 2.83 V
Nominal Impedance	6 Ohms
Crossover Frequencies	1.8 kHz / 2.8 kHz
Enclosure Type	Bass-Reflex
Port Configuration	Rear-Firing Tuned Port
Speaker Type	Passive
Built-In Amplifier	No
Bluetooth	No

PRODUCT DIMENSIONS & WEIGHT

Official JBL dimensions:

Width: 190 mm = 7.48 in
Depth: 255 mm = 10.04 in
Height: 930 mm = 36.61 in

OIKOS CENTER FORMAT

7.48" W × 10.04" D × 36.61" H

Product Weight: 31.61 lb / 14.34 kg

These measurements and weight are directly confirmed by JBL/HARMAN.

PERFECT FOR

Home Theater • Stereo Music Systems • Living Rooms • Entertainment Rooms • Movies • Music • Hi-Fi Audio • Front Left/Right Channels • Audiophile-Style Home Listening

Warranty: 1 Year Manufacturer Warranty
